CBSE Class 12 Physics NCERT Exemplar Solutions: Chapter 8 – Electromagnetic Waves

May 24, 2018 16:48 IST
    NCERT Exemplar Solutions Chapter 8 Electromagnetic Waves
    NCERT Exemplar Solutions Chapter 8 Electromagnetic Waves

    In this article, we bring to you NCERT Exemplar Solutions for all the questions of Class 12 Physics Chapter 8 – Electromagnetic Waves. The difficulty level of these questions is quite higher than the exercise questions usually given at the end of the chapter. These questions are very important for CBSE Class 12 Physics board exams as well as for the competitive exams like JEE Main, JEE Advanced, UPSEE, WBJEE, NEET etc.

    Important Topics of Chapter 8 - Electromagnetic Waves:

    • Displacement current
    • Electromagnetic waves
    • Properties of Electromagnetic Waves
    • Electromagnetic spectrum
    • Types of electromagnetic radiations (Radio waves, microwaves, infrared, visible, ultraviolet, X-rays, gamma rays)
    • Applications/uses of electromagnetic radiations

    Types and number of questions in this chapter:

    Types

    Number of questions

    MCQ I (Multiple choice questions with single correct option)

    8

    MCQ II (Multiple choice questions with multiple correct options)

    5

    VSA (Very short answer type questions)

    7

    SA (Short answer type questions)

    7

    LA (Long answer type questions)

    5

    CBSE Class 12 Physics NCERT Exemplar Solutions: Chapter 12 – Atoms

    Few problems along with their solutions from this chapter are given follows:

    Question:

    Light with an energy flux of 20 W/cm2 falls on a non-reflecting surface at normal incidence. If the surface has an area of 30 cm2, the total momentum delivered (for complete absorption) during 30 min is

    (a) 36 × 10 -5 kg-m/s

    (b) 36 × 10 -4 kg-m/s

    (c) 108 × 104 kg-m/s

    (d) 1.08 × 107 kg-m/s

    Solution:(b)

    We are given, energy flux (f) = 20W/ cm2

    Area (A) = 30cm2

    Time (t) = 30 min

    NCERT Exemplar Class 12 Physics

    = 36 × 10-4 kg-ms-1

    The momentum of the reflected light is 0

    Therefore, the momentum delivered to the surface is given by 36 × 10-4 - 0

    = 36 × 10-4 kg-ms-1

    Question:

    A plane electromagnetic wave propagating along .x-direction can have the following pairs of E and B.

    (a) Ex, By

    (b) Ey, Bz

    (c) Bx , EY

    (d) Ez, By

    Solution:

    As electric and magnetic field vectors E and B are perpendicular to each other as well as perpendicular to the direction of propagation of electromagnetic wave,

    Here in the question electromagnetic wave is propagating along x-direction. So, electric and magnetic field vectors should have either y-direction or z-direction.



    Question:

    Even though an electric field E exerts a force qE on a charged particle yet electric field of an EM wave does not contribute to the radiation pressure (but transfers energy). Explain.

    Solution:

    Since, electric field of an EM wave is an oscillating field and so, the electric force produced by it on a charged particle. This electric force averaged over an integral number of cycles is zero, since its direction changes every half cycle.

    Hence, electric field is not responsible for radiation pressure.

    Question:

    Why is the orientation of the portable radio with respect to broadcasting station important?

    Solution:

    Since, the electromagnetic waves are plane polarized. Hence, the receiving antenna should be parallel to the vibration of the electric or magnetic field of the wave. That is why the orientation of the portable radio with respect to broadcasting station important.

    Question:

    Professor CV Raman surprised his students by suspending freely a tiny Light ball in a transparent vacuum chamber by shining a laser beam on it. Which property of EM waves was he exhibiting? Give one more example of this property.

    Solution:

    We know that, the electromagnetic waves carry energy and momentum like other waves. Since, the electromagnetic wave carries momentum. Therefore, the electromagnetic wave also exerts pressure called radiation pressure. Because of this property, Professor CV Raman surprised his students by suspending freely a tiny light ball in a transparent vacuum chamber by shining a laser beam on it.

    Question:

    Electromagnetic waves with wavelength

    (i) λ1 is used in satellite communication.

    (ii) λ2 is used to kill germs in water purifies.

    (iii) λ3 is used to detect leakage of oil in underground pipelines.

    (iv) λ4 is used to improve visibility in runways during fog and mist conditions.

    (a) Identify and name the part of electromagnetic spectrum to which these radiations belong.

    (b) Arrange these wavelengths in ascending order of their magnitude.

    (c) Write one more application of each.

    Solution:

    (i) Microwave is used in satellite communications.

    So, λ1 is the wavelength of microwave.

    (ii) Ultraviolet rays are used to kill germs in water purifier. So, λ2 is the wavelength of UV rays.

    (iii) X-rays are used to detect leakage of oil in underground pipelines. So, λ3 is the wavelength of X-rays.

    (iv) Infrared is used to improve visibility on runways during fog and mist conditions. So, it is the wavelength of infrared waves.

    (b) Wavelength of X-rays < wavelength of UV < wavelength of infrared < wavelength of microwave.

    ⇒ λ3 < λ2 < λ4 < λ1

    (c)

    (i) Microwave is used in radar.

    (ii) UV is used in LASIK eye surgery.

    (iii) X-ray is used to detect a fracture in bones.

    (iv) Infrared is used in optical communication.

    Link to Download NCERT Exemplar Solutions for Class 12 Physics: Chapter 8 – Electromagnetic Waves

    Types of Question

    Link to Download PDF

    8 MCQ I (Multiple choice questions with single correct option)

    Download Link

    5 MCQ II (Multiple choice questions with multiple correct options)

    Download Link

    7 VSA (Very short answer type questions)

    Download Link

    7 SA (Short answer type questions)

    Download Link

    5 LA (Long answer type questions)

    Download Link
