UP Board Class 12 Physics Model Paper 2023: Download Full PDF

UP Board Class 12 Physics Model Paper 2023: Download the latest model paper for physics released by UPMSP for UP Board Class 12 examinations for the year 2023.

UP Board Class 12 Physics Model Paper 2023
UP Board Class 12 Physics Model Paper 2023

UP Board Class 12 Physics Model Paper 2023: UP Board exams 2023 are fast approaching, and students’ preparation is in full swing. But studying is only half the battle. It’s essential to know the format of the exam and the correct syllabus as well. Many students get nervous attempting exams with a time limit in a highly competitive environment.

Also Check: UP Board class 12 Physics syllabus 2022-23: Download PDF with full syllabus and deleted portions

Physics is a conceptual subject, so it’s important to stay calm during the exam and not forget what you learned. However, knowing the exam pattern and solving model papers beforehand helps you stay composed during the actual examination. It also increases your writing speed.

The Uttar Pradesh Madhyamik Shiksha Parishad, or the UP Board, has released its subject-wise model papers for class 12 students appearing for the 2023 board exams. We have provided the Physics Model Paper for Class 12 in its entirety for you to read. The format and general instructions have also been listed. You can also download the UP Board Class 12 Physics Model Paper 2023 in pdf form at the end of the following article.

Instructions:-

  1. All Questions are compulsory.
  2. This Questions paper have 5 sections : A, B,C,D,E.
  3. Section: A is multiple choice type and each question carries one mark.
  4. Section: B is very short answer type and each question carries one mark.
  5. Section: C is a short answer type I and carries two marks each.
  6. Section: D is of short answer type II and carries three marks each.
  7. Section: E is of long answer type and carries five marks. All four questions of this sections have been given internal choice. You have to do only one question from the choice given in the question.

UP Board Class 12 Physics Model Paper 2023

Section A

1(a) Which of the following electromagnetic radiation has minimum wave length?

  1. Ultraviolet rays
  2. X-rays
  3. Microwaves
  4. Gamma rays

(b) The momentum of a moving particle is p. The wavelength of the matter wave will be-

  1. h/p
  2. p/h
  3. p.h
  4. p

(c) Kirchhoff’s First law is based on conservation of-

  1. Energy
  2. Momentum
  3. Charge
  4. Mass

(d) The reverse saturation current in p-n Junction Diode is due to only-

  1. Minority Charge carriers
  2. Majority charge carriers
  3. Acceptor ion
  4. Donar ion

(e) The majority charge carriers in p -type and n-type semi-conductor are-----------and ------------ respectively.

  1. Electron-electron
  2. Electron Hole
  3. Hole -electron
  4. Electron and Positive ions

(f) The wire of Meter Bridge is made up of-

  1. Iron
  2. Copper
  3. Manganin or Eureka
  4. Steel

Section B

2 (a) What is the minimum wavelength of Balmer series?

(b) Write the formula for Refraction of light at a single spherical surface?

(c) Explain the meaning of Isotope with the help of an example?

(d) Write Radioactive waves in increasing order of their penetrating power?

(e) How can the capacitance of a capacitor be increased?

(f) Give Logic symbol, Boolean Expression and Truth Table for AND gate?

Section C

3 (a) Write the definition and unit of electric flux. What is the meaning of negative electric flux?

(b) 5 Ampere current is flowing in a wire. How many electrons pass per minute through cross section area of the wire?

(c) In the Hydrogen spectrum, find the wavelength of the second line of Balmer series in terms of Rydberg constant(R).

(d) Find the expression for de-Broglie wavelength.

Section D

4(a) Derive the formula for the resultant focal length of two thin lenses placed in contact of each other.

(b) Derive Einstein’s photoelectric equation.  (c) Prove by Brewster’s Law that refracted and reflected rays are mutually perpendicular to each other.

(d) Write Ampere circuital law. Derive the formula for magnetic field intensity at the distance ‘r’ from the current carrying straight wire of infinite length.

(e) The coefficient of self Induction of a coil is 40 milli Henry(40MH) in which electric current becomes 2 ampere to 12 ampere in 5 milli second. Find the value of induced electromotive force in coil.

5(a) The focal length of a thin plano convex lens is 20.0 cm and the refractive index of its material is 1.5. Find radius of curvature of convex surface of this lens.

(b) A small telescope has an objective of focal length 144 cm and an eyepiece of focal length 6.0 cm. Calculate the magnifying power of the telescope. What is the distance between the objective and the eyepiece in the telescope.

(c) What is LED. Show its (vi) characteristics by drawing a circuit diagram.

(d) Explain Kirchhoff’s laws of electric circuits with the help of circuit diagram.

Or

The oscillating magnetic field in a plane electromagnetic wave is given by 3 By=(8 ×10 -6 )sin(2×1011t+300π(Tesla.

  1. i) Calculate the wavelength of electromagnetic wave.
  2. ii) Write down the expression for the oscillating electric field.

(e) The energy of an electron in an excited hydrogen atom is -3.4ev. Calculate the angular momentum of the electron. The energy of electron in nth orbit is -13.6/n2 ev.(h=6.6×10-34 Joule Second)

Section E

6- Define capacitance of a capacitor. Derive the expression for the capacitance of parallel plate capacitor. How can its capacitance be increased.

Or

What is linear charge density? Applying Gauss’s theorem, find the expression for the electric field intensity near a uniformly charged straight wire of infinite length.

7- An electron is moving in a circular path of radius 2×10-10 m with a uniform speed of 3 × 10-6 m/s. Calculate the magnetic field at the centre of the circular path.  (Given:- μ0/4π=10-7 weber per ampere meter/ampere×meter, e=1.6×10-19 coulomb)

Or

Derive the formula for force between two parallel current carrying conductors.

8) Draw a series resonance circuit for L-C-R combination. Derive the formula of resonant frequency for this circuit. How does resonant frequency depend on resistance?

Or

In Young’s experiment while using a source of light of wavelength 4000 A0 , the fringe width of 0.6 mm is obtained at a distance of 2m on the screen. If the entire apparatus is immersed in a liquid of refractive index 1.5 , find the value of fringe width.

9) Explain the process of electric conduction in n-p-n transistor. Why its base is made thin? Why is it more useful in comparison to p-n-p transistor.

Or

Discuss Huygens’s principle of secondary wavelets.

Download UP Board Class 12 Physics Model Paper 2023 PDF

Physics is an important subject for science-stream students. Physics is part of both the engineering and medical entrance exams, so it becomes paramount to learn the concepts well. Doing so will help you ace the board exams and also achieve success after passing Class 12. So study hard and study smart.

All the best!
