CBSE Class 12th Physics Sample Paper and Marking Scheme 2025: Download Free PDF

CBSE Class 12 Physics Sample Paper 2024-25 With Marking Scheme: Are you also a CBSE board class 12 student looking for a revised Physics sample paper to boost your preparation before the exam? Well, don't worry as we always have you covered. This article will provide the students with the Class 12 Physics sample paper. Sample papers or model papers can prove to be the best sources for students to prepare for their upcoming end-term exams.

This sample paper will help the students to get hands-on knowledge about the subject before the final board exams. This way, they can get to know about the important questions along with their total weightage for the exam.

CBSE Class 12 Physics Sample Paper 2024-25

We are providing the Physics sample paper for the students. They can download the link for free in a PDF format. The PDF format is convenient and accessible, allowing it to be saved on computers, laptops and mobile phones.

General Instructions
(1) There are 33 questions in all. All questions are compulsory.
(2) This question paper has five sections: Section A, Section B, Section C, Section D and Section E.
(3) All the sections are compulsory.
(4) Section A contains sixteen questions, twelve MCQs and four Assertion Reasoning based of 1 mark
each, Section B contains five questions of two marks each, Section C contains seven questions of
three marks each, Section D contains two case study-based questions of four marks each and
Section E contains three long answer questions of five marks each.
(5) There is no overall choice. However, an internal choice has been provided in one question in Section
B, one question in Section C, one question in each CBQ in Section D and all three questions in
Section E. You have to attempt only one of the choices in such questions.
(6) Use of calculators is not allowed.
(7) You may use the following values of physical constants wherever necessary.

c = 3 x 10_⁸ m/s
ii. m_e = 9.1 x10^-31 kg
iii. m_p = 1.7 x10^-27 kg
iv. e = 1.6 x 10^-19 C
v. µ0 = 4π x 10^-7 T m 𝑨^−𝟏
vi. h = 6.63 x10^-34 J s
vii. ε₀ = 8.854 x10^-12 𝑪^𝟐𝑵^−𝟏𝒎^−𝟐
viii. Avogadro’s number = 6.023 X 𝟏𝟎^𝟐𝟑 per gram mole

1. A uniform electric field pointing in a positive X-direction exists in a region. Let A be the origin, B be the
point on the X-axis at x = +1 cm and C be the point on the Y-axis at y = +1 cm. Then the potential at
points A, B and C satisfy.
(A) VA < VB  (B) VA > VB.  (C) VA < VC  (D) VA > VC

2. . A conducting wire connects two charged conducting spheres of radii r1 and r2 such that they attain
equilibrium with respect to each other. The distance of separation between the two spheres is very large
compared to either of their radii.
The ratio of the magnitudes of the electric fields at the surfaces of the spheres of radii r1 and r2 is
(A) 𝑟1/𝑟2  (B) 𝑟2/𝑟1  (C)𝑟2²/𝑟1²   (D)𝑟1²/𝑟2²

3. A long straight wire of circular cross-section of radius ҅a᾿ carries a steady current I. The current is
uniformly distributed across its cross-section. The ratio of magnitudes of the magnetic field at a point
a/2 above the surface of the wire to that of a point a/2 below its surface is
(A) 4:1 (B) 1:1 (C) 4: 3 (D) 3:4

4. . The diffraction effect can be observed in
(A) sound waves only (B) light waves only (C) ultrasonic waves only (D) sound waves as well as light waves

5. A capacitor consists of two parallel plates, with an area of cross-section of 0.001 m², separated by a
distance of 0.0001 m. If the voltage across the plates varies at the rate of 10⁸ V/s, then the value of
displacement current through the capacitor is
(A) 8.85 × 10⁻³𝐴  (B) 8.85 × 10⁻⁴𝐴 (C) 7.85 × 10⁻³𝐴 (D) 9.85 × 10⁻³

6. In a series LCR circuit, the voltage across the resistance, capacitance and inductance is 10 V each. If
the capacitance is short-circuited the voltage across the inductance will be
(A) 10 V (B) 10√2 V (C) 10/√2 V (D) 20 V

7. The correct match of column I with column II is

(A) 1-P, 2-R, 3-S, 4-Q  (B) 1-S, 2-P, 3-O, 4-R  (C) 1-Q, 2-P, 3-S, 4-R  (D) 1-S. 2-R, 3-P, 4-Q

8. The distance of the closest approach of an alpha particle is d when it moves with a speed V towards a
nucleus. Another alpha particle is projected with higher energy such that the new distance of the closest
approach is d/2. What is the speed of projection of the alpha particle in this case?
(A) V /2  (B) √2 V  (C) 2 V  (D) 4 V

9. A point object is placed at the centre of a glass sphere of radius 6 cm and refractive index 1.5. The
distance of the virtual image from the surface of the sphere is
(A) 2 cm (B) 4 cm (C) 6 cm (D) 12 cm

10. Colours observed on a CD (Compact Disk) are due to
(A) Reflection (B) Diffraction  (C) Dispersion  (D) Absorption

11. The number of electrons made available for conduction by dopant atoms depends strongly upon
(A)doping level  (B) increase in ambient temperature (C) energy gap  (D) options (A) and (B) both

12. If copper wire is stretched to make its radius decrease by 0.1%, then the percentage change in its
resistance is approximately
(A)–0.4% (B) +0.8% (C) +0.4% (D) +0.2%

For Questions 13 to 16, two statements are given –one labelled Assertion (A) and the other labelled
Reason (R). Select the correct answer to these questions from the options given below.
A. If both Assertion and Reason are true and Reason is the correct explanation of Assertion.
B. If both Assertion and Reason are true but Reason is not the correct explanation of Assertion.
C. If Assertion is true but Reason is false.
D. If both Assertion and Reason are false.

13. Assertion (A): On increasing the current sensitivity of a galvanometer by increasing the number of
turns may not necessarily increase its voltage sensitivity.
Reason(R): The resistance of the coil of the galvanometer increases on increasing the number of
turns.

14. Assertion (A): In a hydrogen atom there is only one electron but its emission spectrum shows many
lines.
Reason (R): In a given sample of hydrogen there are many atoms each containing one electron;
hence many electrons in different atoms may be in different orbits so many transitions from higher
to lower orbits are possible.

15. Assertion (A): Nuclei having a mass number of about 60 are the least stable.
Reason (R): When two or more light nuclei are combined into a heavier nucleus then the binding
energy per nucleon will decrease.

16. Assertion (A): de Broglie's wavelength of a freely falling body keeps decreasing with time.
Reason (R): The momentum of the freely falling body increases with time.

To get the rest of the sample paper, check the link below:

Practising class 12 Physics sample paper not only helps the students to grasp the writing style, which can help them to score well. These sample papers not only assist the students with exam preparation but also serve as a guide, highlighting the key concepts that the students need to focus on. Designed by subject matter experts, the papers help board students self-assess their performance in preparation for the final board exams.

CBSE Class 12 Physics Marking Scheme 2024-25

Now, that the sample paper is being provided to the students, we are also providing the marking scheme along with the answers. After solving the sample papers, the students can take a look at the marking scheme along with answers.

Students will be able to download the PDF for FREE from the link provided below.

At the end of the article, students will be able to get everything that they have been looking for in one place.
